CAN-bus repeater can establish a physical coupling of two CAN-bus systems with the same or different baud rates. There are mainly the following applications:
(1) Increase load nodes and extend the communication distance to achieve CAN-bus coupling.
(2) Achieve CAN system interconnection with different baud rates
(3) With powerful filter functions of Frame ID, accurate acceptance ID configuration minimizes CAN-bus load for removing interference data and differentiating different devices
(4) With strong anti-interference ability, ensure the CAN-bus devices will not cause crash or damage under strong interference


High-speed 32-bit industrial processor
External power supply: DC+ 9~30V
Electrostatic discharge immunity level: contact discharge ± 4KV, air discharge ± 8KV
Electrical fast transient burst immunity level: ±1KV
Surge immunity level: ±1KV
2-channel independent high-speed CAN-bus interface
CAN-bus isolation level: 1500V
CAN-bus use OPEN4 terminal, support 5Kbps~1Mbps baud rate
CAN-bus support CAN2.0A, CAN2.0B, conform to ISO/DIS 11898
Working temperature: -40°C~+85°C
DIN rail mounting method, designed for industry
